Bulk feed truck is also called feed truck, feed tank truck, bulk feed transport vehicle, bulk feed delivery truck, bulk feed transporter truck, etc. It is a special transport vehicle made of high-quality, high-strength steel plate welded forming tanks and equipped with electric or hydraulic auger unloading system on the basis of various types of trucks or second-class chassis. Bulk feed truck consists of the chassis, the loaded feed tank, the discharge auger system and the electro-hydraulic operating system.
Optional feed tank capacity: 12cbm to 42cbm bulk feed truck, 40cbm to 70cbm bulk feed trailer.
Optional quantity of compartments: 2-5 warehouses, 3 warehouses as our standard.
Optional brands of chassis: Dongfeng, FOTON, JAC, SHACMAN, HOWO bulk feed trucks for choose.
Discharge method: Electric or hydraulic screw conveyer discharge system, electric can be powered by a generator.
Specifications of Dongfeng Tianjin 4x2 22m3 Bulk Feed Truck:
|
Item |
Parameter |
|
|
Vehicle Main parameter |
Vehicle model |
CLW5181ZSLD5 bulk feed truck |
|
Cab type |
Dongfeng single sleeper cab, flat proof, air conditioning |
|
|
Overall dimension(L×W×H)(mm) |
9200×2500×3850 |
|
|
Axle number |
2 |
|
|
Drive type |
4*2 |
|
|
Steering type |
LHD with hydraulic power steering |
|
|
Max. Drive Speed (km/h) |
98 |
|
|
Curb weight (kg) |
Approx 9270 |
|
|
Chassis parameter |
Chassis model |
DFH1180BX1V |
|
Chassis brand |
Dongfeng Tianjin |
|
|
Wheelbase |
5000 mm |
|
|
Transmission |
Manual ,8 speed forward and 1 reverse |
|
|
Brakes |
Air brake |
|
|
Tire |
10.00R20, 6 with 1 Spare tire |
|
|
Engine parameter |
Engine brand |
Dongfeng Cummins |
|
Model |
ISB180-50 |
|
|
Fuel type |
Diesel |
|
|
Horse Power(kw)/(hp) |
132kw (180hp) |
|
|
Displacement(ml) |
4500 |
|
|
Emission Standard |
Euro 5 |
|
|
Superstructure Parameter |
1. Transport Medium |
Kinds of bulk feed |
|
2. Main composition |
Chassis, feed silo, feed inlet, discharge auger system, operation electric hydraulic system, etc. |
|
|
3.Tank volume(m3) |
22m3 |
|
|
4.Tank material |
High quality carbon steel |
|
|
5. Warehouse |
With 3 units separate warehouses to load different kinds of feed |
|
|
6. Discharger type: |
Hydraulic auger |
|
|
7. Performance parameter: |
(1).Average discharge rate(kg/min):500-600; (2).Discharge system rotation angle:360 degree ,system elevation angle:60 degree; (3).Maximum horizontal distance:6m, Vertical distance:7m-8.5m |
|
|
Product cycle |
30-35 working days |
|
