Explosive transport truck, also known as explosion transport vehicle, explosive equipment transport vehicle, blasting equipment transporter, detonator transport vehicle, dangerous goods transport truck, etc. It is a kind of special cargo truck with box structure, which can be used for explosives, detonators, fireworks and firecrackers transportation,etc. It have the feature of high intensity, fire retardant, waterproof, prevent electrostatic spark, fireworks alarm and burglar alarm, etc.
Specifications of JMC 4x2 4.2m Explosive Transport Truck:
Item | Unit | Parameter | |
Product name | JMC 4x2 explosive transport truck | ||
Vehicle model | CLW5041XQYJ6 | ||
Chassis model | JX1041TG26 | ||
Wheel base | mm | 3360 | |
Overall dimensions | 5995×2150×3030 | ||
Box dimensions | 4150×2050×2000 | ||
GVW | kg | Appro×4495 | |
Curb weight | Appro×3080 | ||
Payload | Appro×1285 | ||
Engine | Model | CLW5041XQYJ6 | |
Manufacturer | Jiangling Motors Co., Ltd (JMC) | ||
Exhaust/kw | 2499/90 | ||
Emission standard | Euro VI | ||
Max speed | km/h | 90 | |
Traction system | 4x2 | Transmission | 5-speed with over drive |
Tire specification | 7.00R16 | Number of axles | 2 |
Driver’s cab | Single row flat cab, with A/C, ABS, electric windows | ||
Remark | Transport of explosives, detonators, fireworks and firecrackers, etc |
Cargo van box configuration:
1. Van body material: High quality large shaped steel pipe skeleton, exterior decoration of cold-rolled steel plate, interior quality aluminum alloy plate, filled with 5cm thick insulation and flame retardant material in the middle.
2. There are rainproof natural ventilation windows above both sides of the van, with flame retardant and static conductive adhesive plates laid at the bottom. Fixed pull rings are installed on both sides of inside the van, and goods are bundled with straps to avoid movement.
3. The top of inside the van is equipped with a smoke detector, and an anti-theft alarm is installed above the door frame. The outer side of the compartment is equipped with a clearance light and a fire extinguisher bracket, and is equipped with two fire extinguishers.
4. There are words such as "No Smoking" and "Explosion" on the van body, and reflective signs are affixed around the body. There are safety notices and dangerous goods signs posted on the back door.
5. Install two anti-static adhesive tapes at the rear of the vehicle, and install safety triangle lights on the top of the cab.
6. With side doors and galvanized hardware.
