FOTON 4x2 4m Explosive Transport Truck

Loading capacity: 4-5 tons

Box inner dimension: 4150×2050×2000 mm


Chassis: FOTON AUMARK, 4x2

Transmission: 5-speed manual


Emission standard: Euro 3, Euro 4, Euro 5, Euro 6

Steering wheel: LHD /RHD

Inquire Now Prev Product
Product parameter

Explosive transport truck, also known as explosion transport vehicle, explosive equipment transport vehicle, blasting equipment transporter, detonator transport vehicle, dangerous goods transport truck, etc. It is a kind of special cargo truck with box structure, which can be used for explosives, detonators, fireworks and firecrackers transportation,etc. It have the feature of high intensity, fire retardant, waterproof, prevent electrostatic spark, fireworks alarm and burglar alarm, etc.


Specifications of FOTON 4x2 4m Explosive Transport Truck:

Item

Unit

Parameter

Product name

FOTON 4x2 explosive transport truck

Vehicle model

CLW5041XQYB3

Chassis model

BJ1065VDJD6

Wheel base

mm

3360

Overall dimensions

5995×2150×3030

Box dimensions

4150×2050×2000

GVW

kg

Appro×4495

Curb weight

Appro×3080

Payload

Appro×1285

Engine

Model

BJ493ZLQV1

Manufacturer

Beiqi FOTON

Exhaust/kw

2771/80

Emission standard

Euro 3

Max speed

km/h

90

Traction system

4x2

Transmission

5-speed with over drive

Tire specification

7.00R16

Number of axles

2

Drivers cab

Single row flat cab,manual windows

Remark

Transport of explosives, detonators, fireworks and firecrackers, etc


Cargo van box configuration:


1. Van body material: High quality large shaped steel pipe skeleton, exterior decoration of cold-rolled steel plate, interior quality aluminum alloy plate, filled with 5cm thick insulation and flame retardant material in the middle.


2. There are rainproof natural ventilation windows above both sides of the van, with flame retardant and static conductive adhesive plates laid at the bottom. Fixed pull rings are installed on both sides of inside the van, and goods are bundled with straps to avoid movement.


3. The top of inside the van is equipped with a smoke detector, and an anti-theft alarm is installed above the door frame. The outer side of the compartment is equipped with a clearance light and a fire extinguisher bracket, and is equipped with two fire extinguishers.


4. There are words such as "No Smoking" and "Explosion" on the van body, and reflective signs are affixed around the body. There are safety notices and dangerous goods signs posted on the back door.


5. Install two anti-static adhesive tapes at the rear of the vehicle, and install safety triangle lights on the top of the cab.


6. With side doors and galvanized hardware.
